Nisshinbo NJR NJT8376U series Universal Ku-band 6W BUC
Quantity:
|
Model No. |
RF Frequency |
Output Power |
IF Connector |
|
NJT8376UN |
13.75 to 14.50 GHz |
6W |
N-Type |
|
NJT8376UF |
13.75 to 14.50 GHz |
6W |
F-Type |
Frequency Organization
RF Frequency: 13.75 to 14.5 GHz
IF Frequency: 950 to 1,700 MHz
LO Frequency: 12.8 GHz
High Efficiency & Low Distortion Output Power
P1dB: +37.8 dBm min. over temperature
ACPR: -26 dBc @ Pout = +37.0 dBm
Power Consumption: 34 W
Ultra-compact & Ultra Light Weight
Weight: 540 g
Others
RoHS Compliance
