Nisshinbo NJR NJT8306U series Universal Ku-band 6W BUC
Quantity:
|
Model No. |
RF Frequency |
Output Power |
IF Connector |
|
NJT8306UN |
13.75 to 14.50 GHz |
6W |
N-Type |
|
NJT8306UF |
13.75 to 14.50 GHz |
6W |
F-Type |
Frequency Organization
RF Frequency: 13.75 to 14.5 GHz
IF Frequency: 950 to 1,700 MHz
LO Frequency: 12.8 GHz
High Temperature Operating Guarantee
Operating Guarantee Temperature Range: -40 to +65 ℃
High Efficiency & Low Distortion Output Power
P1dB: +37.8 dBm min. over temperature
ACPR: -30 dBc @ Pout = +37.8 dBm
Power Consumption: 40 W
Small Size & Light Weight
Weight: 1.2 kg
Others
LED Indicator Equipped
RoHS Compliance
