Nisshinbo NJR NJT8318U series Universal Ku-band 8W BUC

Quantity:

Model No.	RF Frequency	Output Power	IF Connector	Options
NJT8318UN	13.75 to 14.50 GHz	8W	N-Type	Power Supplied from IF Connector
NJT8318UF	13.75 to 14.50 GHz	8W	F-Type	Power Supplied from IF Connector
NJT8318UNM	13.75 to 14.50 GHz	8W	N-Type	Power Supplied from MS Connector
NJT8318UFM	13.75 to 14.50 GHz	8W	F-Type	Power Supplied from MS Connector
NJT8318UNA	13.75 to 14.50 GHz	8W	N-Type	Power Supplied from AC/DC PSU
NJT8318UFA	13.75 to 14.50 GHz	8W	F-Type	Power Supplied from AC/DC PSU
NJT8318UNK	13.75 to 14.50 GHz	8W	N-Type	Power Supplied from IF Connector
NJT8318UFK	13.75 to 14.50 GHz	8W	F-Type	Power Supplied from IF Connector
NJT8318UNMK	13.75 to 14.50 GHz	8W	N-Type	Power Supplied from MS Connector
NJT8318UFMK	13.75 to 14.50 GHz	8W	F-Type	Power Supplied from MS Connector
NJT8318UNMR	13.75 to 14.50 GHz	8W	N-Type	Power Supplied from MS Connector
NJT8318UFMR	13.75 to 14.50 GHz	8W	F-Type	Power Supplied from MS Connector
NJT8318UNMA	13.75 to 14.50 GHz	8W	N-Type	Power Supplied from AC/DC PSU
NJT8318UFMA	13.75 to 14.50 GHz	8W	F-Type	Power Supplied from AC/DC PSU

Frequency Organization

RF Frequency: 13.75 to 14.5 GHz

IF Frequency: 950 to 1,700 MHz

LO Frequency: 12.8 GHz

High Efficiency & Low Distortion Output Power

P1dB: +39 dBm min. over temperature

ACPR: -28 dBc @ Pout = +38 dBm

Power Consumption: 79 W

High Temperature Operating Guarantee

Operating Guarantee Temperature Range: -40 to +75 ℃

Power Requirement Line-up

DC Power Voltage Range: +18 to +60 VDC

AC Power Option

M&C Option

FSK Communications M&C

RS-232C M&C

Small Size & Light Weight

Weight: 2.4 kg

Others

LED Indicator Equipped

RoHS Compliance
